DuckDB SQL

canardstack does not expose SQL through its HTTP API. Use DuckDB, MotherDuck, or another SQL client when you want direct access to the stored DuckLake tables.

This path is for operators and analysis. It bypasses the compatibility API guards that Grafana uses, so put your own bounds on time ranges and row counts.

Local DuckLake

When canardstack runs on the host with default settings, it stores the local DuckLake catalog and data files under .canardstack.

Open DuckDB from the repository root:

duckdb

Load DuckLake and attach the catalog:

INSTALL ducklake;
LOAD ducklake;

ATTACH 'ducklake:.canardstack/canardstack.ducklake' AS canardlake
  (DATA_PATH '.canardstack/storage');
USE canardlake;

Then query the physical telemetry tables:

SELECT timestamp, service_name, severity_text, body
FROM logs
WHERE timestamp >= TIMESTAMP '2026-05-25 00:00:00'
ORDER BY timestamp DESC
LIMIT 100;

SELECT timestamp, trace_id, span_id, service_name, span_name, duration
FROM spans
WHERE timestamp >= now() - INTERVAL 1 HOUR
ORDER BY timestamp DESC
LIMIT 100;

SELECT timestamp, metric_name, service_name, value
FROM metric_gauge
WHERE timestamp >= now() - INTERVAL 1 HOUR
ORDER BY timestamp DESC
LIMIT 100;

SELECT timestamp, metric_name, service_name, value, aggregation_temporality,
       is_monotonic
FROM metric_sum
WHERE timestamp >= now() - INTERVAL 1 HOUR
ORDER BY timestamp DESC
LIMIT 100;

Tables

The v0 telemetry tables are:

Table	Signal
logs	OTLP log records
spans	OTLP spans
metric_gauge	OTLP gauge datapoints
metric_sum	OTLP sum datapoints

Each table has an event-time timestamp, storage-added ingested_at, and source_format. Resource, scope, log, span, and metric attributes are stored as JSON strings in their corresponding *_attributes columns.

Compatibility labels such as deployment_environment, http_route, and http_method are derived by canardstack for Grafana. They are not physical columns in the raw telemetry tables.

Metadata summary

Grafana discovery endpoints use the metadata_summary table. It is useful when you want to see what labels, tags, services, and metrics canardstack has summarized:

SELECT signal, kind, name, value, row_count, first_seen, last_seen
FROM metadata_summary
ORDER BY last_seen DESC
LIMIT 100;

MotherDuck

For a MotherDuck-backed DuckLake, attach the md: URI directly:

export MOTHERDUCK_TOKEN='<your-motherduck-token>'
duckdb

ATTACH 'md:test-ducklake' AS canardlake;
USE canardlake;

SELECT timestamp, body
FROM logs
ORDER BY timestamp DESC
LIMIT 20;

Use the same md: value that canardstack uses in CANARDSTACK_DUCKLAKE_ATTACH_URI.

Docker Compose data

The default Compose stack stores canardstack data in the named Docker volume canardstack-data. For direct SQL, the simpler path is to run canardstack on the host and query .canardstack, or use MotherDuck. If you need to inspect a Compose volume, mount or copy it first, then attach the DuckLake catalog with the matching DATA_PATH.

Keep SQL bounded

DuckLake keeps the data open to normal DuckDB analysis. That also means a broad scan can be broad. Prefer queries with:

• a timestamp predicate
• a LIMIT
• selected columns instead of SELECT *
• explicit service_name, metric_name, or trace_id filters when available
