canardstack

canardstack is an experimental, single-binary observability backend for storing OpenTelemetry logs, traces, gauge metrics, and sum metrics in DuckLake.

It accepts OTLP/HTTP, normalizes telemetry into Arrow batches, stores immutable Parquet-backed DuckLake segments, and exposes bounded Prometheus, Loki, and Tempo compatibility APIs for Grafana-style clients.

What This Is

• A single Rust process with synchronous std-library HTTP serving.
• Local DuckLake storage by default, with remote DuckLake attach support.
• A focused compatibility surface for inspecting telemetry through existing Prometheus, Loki, Tempo, and DuckDB-compatible tools.

What This Is Not

• A full observability suite.
• A multi-tenant production service.
• A full Prometheus, Loki, Tempo, PromQL, LogQL, or TraceQL implementation.

Start Locally

Install and start canardstack. With no options, it uses local DuckLake storage under .canardstack and listens on 127.0.0.1:4318.

cargo install --locked canardstack
canardstack

In another terminal, send one OTLP/HTTP JSON log:

curl -sS -X POST http://127.0.0.1:4318/v1/logs \
  -H 'Authorization: Bearer dev-canardstack-key' \
  -H 'Content-Type: application/json' \
  --data '{"resourceLogs":[{"scopeLogs":[{"logRecords":[{"timeUnixNano":"1779667200000000000","body":{"stringValue":"hello world"}}]}]}]}'

Give the scheduler a moment to seal the row into DuckLake, then query it directly from the DuckDB CLI:

sleep 2
duckdb

INSTALL ducklake;
LOAD ducklake;
ATTACH 'ducklake:.canardstack/canardstack.ducklake' AS canardlake
  (DATA_PATH '.canardstack/storage');
USE canardlake;

SELECT timestamp, body
FROM logs
WHERE body = 'hello world'
ORDER BY ingested_at DESC
LIMIT 1;

Schema

canardstack stores four DuckLake telemetry tables: logs, spans, metric_gauge, and metric_sum. The physical columns come from otlp2records, with two local storage columns added by canardstack: ingested_at and source_format.

Arbitrary OpenTelemetry resource, scope, log, span, and metric attributes are stored as JSON strings in attribute columns. Grafana-facing labels such as deployment_environment, http_method, and http_route are derived from those canonical columns in bounded query and metadata paths instead of being stored as separate raw-table columns.

Schema stability

The current DuckLake schema is experimental and will evolve with breaking changes before canardstack is ready for stable production use. Medium-term schema work is expected to align more closely with the OpenTelemetry Arrow data_model.md.

Demo

For the full OpenTelemetry demo workflow, use the Demo guide.

Start The Stack

Start canardstack and Grafana with local DuckLake storage:

docker compose up --build

The default local stack exposes:

• canardstack: http://localhost:4318
• Grafana: http://localhost:3000

Send Sample Telemetry

In another terminal, run the smoke client:

docker compose run --rm smoke

The smoke workload sends logs, a multi-span trace, gauge samples, and cumulative sum samples through OTLP/HTTP. It also checks storage health and the Prometheus, Loki, and Tempo-compatible query paths.

Open Grafana

Open the provisioned dashboard:

http://localhost:3000/d/canardstack-overview/canardstack-overview

Use admin/admin if Grafana asks for credentials.

Deploy

Use the send telemetry guide to configure OTLP/HTTP producers. Use the deployment docs for MotherDuck, GCP Cloud Run, and AWS ECS/Fargate options.

Query Data

Use the Grafana datasource guide to connect metrics, logs, and traces. Use the DuckDB SQL guide to query the DuckLake tables directly.

Build From Source

For host development:

cargo check
cargo test
cargo run

The host server defaults to 127.0.0.1:4318.
